Solis S6-EH1P6K-L-PLUS 6KW IP66 Hybrid Solar Inverter (Single Phase)

Advanced Hybrid Solar Power — Solis S6-EH1P6K-L-PLUS 6KW IP66 Inverter

The Solis S6-EH1P6K-L-PLUS 6KW Hybrid Solar Inverter is a premium single-phase hybrid inverter engineered for residential and commercial solar installations in Pakistan. With seamless solar, grid, and generator integration, automatic UPS switching within 10 seconds, 200% surge power capacity, IP66 outdoor protection, and a 7-inch LCD touchscreen with Bluetooth and Wi-Fi monitoring, the Solis S6-EH1P6K-L-PLUS delivers unmatched reliability, flexibility, and smart energy management.

Key Features

• 6KW Rated Output — suitable for medium to large residential and commercial loads
• Seamless Integration — supports solar, grid, and generator connectivity
• Automatic UPS Switching — within 10 seconds for uninterrupted backup power
• 200% Surge Power for 10 Seconds — handles high-inrush motor and appliance loads
• Max PV Array Size: 12KW — supports large solar panel arrays
• MPPT Voltage Range: 90–435V — wide solar string compatibility
• Battery Compatible: Li-ion & Lead-acid — flexible storage options
• Max Charge/Discharge Current: 135A
• High Efficiency: 96.2% (Max), 96.1% (EU)
• IP66 Protection — fully dust & water resistant, suitable for outdoor installation
• 7-inch LCD Display — with Bluetooth & Wi-Fi app-based monitoring
• Peak Shaving Control — in self-use and generator modes to optimize energy costs
• Up to 36KW Parallel Connection — scalable for larger systems
• Advanced MPPT & Peak Shaving — optimized solar utilization

Technical Specifications

• Rated Power: 6KW | Type: Single Phase | Operation: Hybrid
• Max PV Array: 12KW | MPPT Voltage Range: 90–435V
• Battery: Li-ion / Lead-acid | Max Charge/Discharge: 135A
• Efficiency: 96.2% Max | Surge Power: 200% for 10 seconds
• Protection: IP66 | Display: 7-inch LCD
• Connectivity: Bluetooth, Wi-Fi | Parallel: Up to 36KW
• Dimensions: 335×560×253mm | Weight: 23.5kg
• Operating Temp: -40°C to +60°C
• Brand: Solis | Model: S6-EH1P6K-L-PLUS

Power your home through every outage with the Solis S6-EH1P6K-L-PLUS. Order today from Sunshine Solar.
